Woven · 105 mesh
105 Mesh – .0033" Wire Diameter – Type 430 Stainless Steel Woven Wire
SKU · KU105-0033N105 mesh.0033" Wire
Type 430 stainless steel woven wire mesh — 105 mesh with a .0033" wire diameter, giving a 0.006" (0.16 mm) square opening and roughly 43% open area.
Type 430 is a ferritic, magnetic stainless — economical, with good corrosion resistance in indoor and mild environments. A dependable choice for fine filtration, sieving, and particle control.
Supplied as 60" wide material, cut to your dimensions. Stocked in Hayward, California — request a quote for pricing, custom sizes, and fabrication.
// Specifications105 mesh · 430 SS
- Construction
- Woven
- Material / Alloy
- 430 SS
- Mesh Count
- 105 mesh
- Wire Diameter
- .0033"
- Opening Size
- 0.0062" · 158 µm
- Open Area
- 43%
Need a hand?
Custom widths, finishes or quantities — our team can quote anything we sell.
Talk to a real person →
Quick question? Ask Meshy (AI) →
From Hayward, CA → Your Door
/ 01
Logistics & Lead Time
How It Ships
Cut, Rolled, Shipped.
Cut & Rolled
Pulled from stock or cut-to-size at our Hayward warehouse. Wrapped in a protective sleeve for transit.
Out The Door
Standard rolls ship in 1–3 business days via freight or LTL. Tracking + MTR docs sent on dispatch.
/ 02
Where It Goes To Work
Typical Applications
Cut-to-spec mesh, screen and cloth — engineered for the jobs our customers run every day.
Filtration
Liquid, fuel and hydraulic filters, strainer elements and filter discs.
Sieving & Lab
Test sieves, particle sizing and sample separation.
Food & Beverage
Sifters, strainers and brewing screens in food-safe stainless.
Shielding & Venting
EMI/RFI shielding, battery and sensor vents, acoustic screens.
